Concrete Mobile Batching Machine (RM800, RM1050 & RM1400)
| Business Type | Manufacturer, Exporter, Supplier, Retailer, Wholesaler |
| Brand Name | ACME |
| Power(W) | 10, 15, 20HP |
Preferred Buyer From
| Location | India ( Telangana) |
concrete mobile batching machine (reversible drum mixer)offered by us is manufactured using latest technology for ensuring excellent performance. The array of concrete mobile batching machine we manufacture is used extensively in construction industry for mixing concrete. Our concrete mobile batching machine is appreciated for its high durability, excellent performance and various other notes features.
special attributes :
- can mix aggregate up to 80mm
- mix in forward rotation
- discharge in reverse rotation
- excellent performance
- long performing life
- sturdy construction
components :
- pump for feeding water tank
- water tank with measuring scale
- digital display of weights
- heavy duty hydraulic system
- centralized lubrication system
- handle for unloading incase of power failure
- automised water and admixture dozing system
- four wheels for easy mobility
application area :
- construction industry
Specifications
Technical Specification Concrete Mobile Mini Batching Machine RM800
| Descritpion | Concrete Mobile Mini Batching Machine RM800 | Concrete Mobile Mini Batching Machine RM1050 | Concrete Mobile Mini Batching Machine RM1400 |
| Model | RM 800E | RM1050 | RM1400 |
| Drum Capacity (Max) | 0.6 Cu.Mtr (21 CFT) per batch | 0.75 Cu.Mtr | 0.9 Cu.Mtr |
| Machine Output Capacity (Max): | 12 Cu.mtr / hour | 15 Cu.mtr / hour | 20 Cu.mtr / hour |
| Hopper Capacity Three Bin | 800 LTRS | 1050 LTRS | 1400 LTRS |
| Hopper Lifting Capacity | 1250 KG Maximum weight of Cement, Sand & Metal should be 1250 Kg |
1800 KG Maximum weight of Cement, Sand & Metal should be 1800 Kg |
2400 KG Maximum weight of Cement, Sand & Metal should be 2400 Kg |
| Water Tank Inbuilt Water Tank | 160 Liters | 250 Liters | 275 Liters |
| Motor | 10 HP, 3 Phase Electrical Motor | 15 HP, 3 Phase Electrical Motor | 20 HP, 3 Phase Electrical Motor |
